Locking Pin (Q20S)

  • Increase tension
  • Ensure that the tray is fully positioned to avoid over-positioning
  • Suitable for short cone ball lock type Q20S zero locator
  • Locking Pin (Q20S)
  • Locking Pin (Q20S)
  • Locking Pin (Q20S)
Detail drawing
  • Locking Pin (Q20S)
  • Locking Pin (Q20S)
  • Locking Pin (Q20S)
Contact us
Zero Point Clamping System Product parameters Zero Point Clamping System Drawing Zero Point Clamping System Data download Zero Point Clamping System Related accessories
Product Overview

Locking pin, surface hardened.
Diameter 31.8mm, height 41.7mm, weight 140g.
It not only increases the tensioning force, but also ensures that the tray is completely positioned to avoid over-positioning.
Suitable for short cone ball lock type Q20S zero locator.

Locking Pin (Q20S)
Product Features

  • Surface hardening treatment;

  • Ensure that the tray is fully positioned to avoid over-positioning;

Zero Point Clamping System

  • Play the role of increasing tension;

  • Suitable for short cone ball lock type Q20S zero locator.

Product dimension diagram

Order number ØDN ØD1 ØD2 H1 H2 Weight(g)
SJJT-20S 31.8  25  M12(Through) 5  36.7  140
